OPNIC Installation Guide

The following page describes the installation procedure of an OPNIC - including connectivity to the OPX1000, configuration, and initialization.

Components

OPNIC Hybrid Link - Physical Components

• OPNIC: OP Network Interface Card, installed in the host server's PCIe port
• Server: Server / Computer driving the classical computation. Also referred to as the "OPNIC host server"
• OPX1000: Ultra low latency Quantum control and readout controller

Server Installation

The OPNIC host server must be configured to communicate for it to function. If it is not yet configured, follow the instructions here

OPNIC Hybrid Link Software & Firmware Components

Software on the server consists of three open-source software components that are required to be installed on the server:

1. OPNIC Driver: A kernel driver for the OPNIC PCIe card
2. OPNIC SDK: A shared library that is used by user’s application on the server
3. OPNIC CLI tool: A CLI interface for managing the OPNIC (for example, a one-time sync with QOP, updating card FW, etc.)

Warning

Avoid running sudo apt upgrade on the server, as it may trigger unintended driver updates that are incompatible with the provided OPNIC drivers.

OPNIC Installation in the host server

Step 4 can be used to update the OPNIC firmware. If the system was previously configured, you can skip directly to step 4.

Step 1: OPNIC Mechanical Assembly

The assembly instructions apply to a specific tray-based riser configuration. Server types and PCIe mounts may differ; always follow the manufacturer’s instructions for your model.

• Mechanical assembly manual - tray-based riser server OPNIC Assembly Guide

Step 2: OPNIC Connection Schema

OPNIC communication requires an Ethernet connection between the OPX1000 chassis and the server and an optical connection between the OPNIC and the OPX1000 chassis. Please follow these guidelines:

• Make sure slot 1 is populated by an FEM or contact Quantum Machines support for an alternative connectivity configuration.
• Connect the 2 QSFP-MPO adapters to the relevant ports in the OPNIC.

• Connect the MPO optical cables from the OPNIC to the OPX1000 according to the diagram:

  • Make sure to connect Comm 2 to the right OPNIC port (orientation according to the sketch).

  • Make sure both MPO optical cables are identical and of the same length.



  Note

  The sketch illustrates the connection to a Rev. C chassis.

  If the OPNIC is connected to a Rev. B chassis, use the provided adapter kit, or use a patched MPO optical cables, which are sometimes pink.

• Network Communication - Ethernet connections should be based on the specific site/IT connectivity guidelines.

  Make sure you can ping the OPX1000 from the server. The easiest way is to ensure they are on the same subnet. Alternatively, routing can be defined, please contact your IT department for support.

Step 3: OPNIC Drivers Installation and Update

1. Copy the OPNIC software package provided by Quantum Machines into the server

2. Add execute permissions:

   cd opnic-driver/scripts
   chmod +x install.sh
   chmod +x uninstall.sh
   cd ../..


3. Install Driver:

   cd opnic-driver
   make
   sudo make install
   cd ..


4. Install SDK:

   sudo apt install libssl-dev
   cd opnic-sdk
   cmake --preset cuda
   sudo cmake --build build -- install
   cd ..


5. Verify installation of opnic libraries:

   ll /usr/local/lib


   And verify that the following files are present: libopnic.so, libopnic-cuda.so.

6. Install CLI:

   cd opnic-cli
   cmake . -B build -G Ninja
   sudo cmake --build build --target install
   cd ..


Step 4: OPNIC Firmware Update

The OPNIC firmware consists of two separate images which can be updated using the OPNIC CLI tool:

FPGA Image: The bitfile that is loaded into the OPNIC FPGA. This image is responsible for the PCIe interface and the communication with the OPX.

PLL configuration: The OPNIC clock configuration, will rarely update.

1. Check the version by running:

   opnic -vv version


2. Validate that the output indeed shows the latest FPGA and PLL images:

   Image version: 05.00.57
   PLL Version: 0xac


3. Update by flashing the latest image when versions are outdated:

   opnic flash --image <path_to_image>
   opnic flash --pll <path_to_pll_file>


   Note

   Applicable when installing a new system or updating from a version earlier than 5.00.57

   while connected to the internet run:

   sudo update-pciids


4. Once the flash has ended, reset the card by running:

   opnic reset-card


5. Restart the server:

   sudo reboot


6. Firmware update is supported by new drivers.

   • Follow the driver installation steps described in Step 3.
   • Repeat Firmware validation upon completion.

Appendix 1: Server Installation

OPNIC host server minimal configuration:

• OS:

  • UBUNTU Ver. 22.04.5, 24.04
  • Fedora CoreOS 42.2x with GNU compiler 15.2.1

• UBUNTU Ver. 22.04.5

• GCC13
• CMake ≥ 3.25.5
• make
• NVidia driver linux-nvidia-64k-hwe-22.04
• Cuda toolkit 12-8

Recommended Installation Steps

Note

Next steps are for a specific GH200 server by QCT, exact details may vary based on the server model and configuration.

1. Preparations

• Connect the server with two power cables.
• Connect an ethernet cable to the Baseboard Management Controller (BMC) panel. This is next to the front power button.
• Connect an ethernet cable to a free ethernet port, this should be in the same subnet as the OPX.
• Connect a screen and keyboard to find the BMC IP through the BIOS -

2. Firmware updates

Update the server's firmware, full steps (for a specific update) can be found in this guide

Warning

The following installation notes apply to Ubuntu 22.04 on an arm64 system. Make sure to install the NVIDIA drivers that match your configuration. Applying the wrong configuration may stall your system.

3. Linux installation

Download and install Ubuntu 22.04.5 ARM64 Server: link: - Load it onto a disk-on-key as bootable - In MacOS (replace below # with the disk number, find it with diskutil list): diskutil unmountDisk /dev/disk# sudo dd if=~/Downloads/ubuntu-22.04.5-live-server-arm64.iso of=/dev/rdisk# bs=4m - Insert disk-on-key in the BMC panel usb port, and power on the GH200 - The installation will start automatically, follow the instructions on the screen.

4. Install gcc13

Run the following commands:

sudo apt install software-properties-common -y
sudo add-apt-repository ppa:ubuntu-toolchain-r/test -y
sudo apt update
sudo apt install gcc-13 g++-13 -y
# make gcc13 the default version
sudo update-alternatives --install /usr/bin/gcc gcc /usr/bin/gcc-13 100
sudo update-alternatives --install /usr/bin/g++ g++ /usr/bin/g++-13 100
# verify
gcc --version
sudo ln -s /usr/bin/gcc /usr/bin/cc

Edit the /.bashrc file and add the next string at the end:

export CC=gcc

Run bashrc and run configuration:

source ~/.bashrc

5. Install cmake

Run the following commands:

# download cmake installer
wget https://github.com/Kitware/CMake/releases/download/v3.31.6/cmake-3.31.6-linux-aarch64.sh

# grant execution permission
sudo chmod +x cmake-3.31.6-linux-aarch64.sh

# run it. agree to the license and type 'Y' when it asks if you want to install it in the default folder
./cmake-3.31.6-linux-aarch64.sh

# move it to /opt
sudo mv cmake-3.31.6-linux-aarch64/ /opt/cmake-3.31.6

# add symbolic links in /usr/local/bin to point to the cmake you just installed
sudo ln -s /opt/cmake-3.31.6/bin/ccmake /usr/local/bin/ccmake
sudo ln -s /opt/cmake-3.31.6/bin/cmake /usr/local/bin/cmake
sudo ln -s /opt/cmake-3.31.6/bin/cmake-gui /usr/local/bin/cmake-gui
sudo ln -s /opt/cmake-3.31.6/bin/cpack /usr/local/bin/cpack
sudo ln -s /opt/cmake-3.31.6/bin/ctest /usr/local/bin/ctest

# test
cmake --version
# install Ninja
sudo apt install ninja-build -y

6.Install make

Run the following commands:

sudo apt install make

7. Install and update Nvidia driver

Warning

Make sure to install the NVIDIA drivers that match your configuration. Applying the wrong configuration may stall your system.

Run the following commands to update the system and install the NVIDIA optimized Ubuntu kernel variant and reboot:

sudo DEBIAN_FRONTEND=noninteractive apt purge linux-image-$(uname -r) linux-headers-$(uname -r) linux-modules-$(uname -r) -y
sudo apt update
sudo apt install linux-nvidia-64k-hwe-22.04 -y
sudo reboot now

Updating Nvidia driver:

sudo apt-get install linux-headers-$(uname -r)
wget https://developer.download.nvidia.com/compute/cuda/repos/ubuntu2204/sbsa/cuda-keyring_1.1-1_all.deb
sudo dpkg -i cuda-keyring*.deb
sudo apt-get update
sudo apt-get install cuda-toolkit-12-8 -y
sudo apt-get install nvidia-kernel-open-575 cuda-drivers-575 -y
sudo reboot

Check installation with:

nvidia-smi

To check and determine whether the CPU and GPU memory subsystems are up and functional, run the following commands

lsmem

map nvcc:

grep -q 'export PATH=/usr/local/cuda-12.8/bin:$PATH' ~/.bashrc || echo 'export PATH=/usr/local/cuda-12.8/bin:$PATH' >> ~/.bashrc && source ~/.bashrc

8. Validate correct gcc version

This step ensures the correct GCC version is used, as certain installations may inadvertently trigger a rollback to an earlier version

# make gcc13 the default version
sudo update-alternatives --install /usr/bin/gcc gcc /usr/bin/gcc-13 100
sudo update-alternatives --install /usr/bin/g++ g++ /usr/bin/g++-13 100
# verify
gcc --version
